QTC Intelligent Traffic Signal Controller

Description

Logic Rack Sizes:

• Multiple sizes are available ranging from a little as 4SG all the way up to 32SG, in increments of 4SG.
• From 16 up to 48 loop detectors plus from 16 up to 48 external inputs.

Traffic Control:

• The HADRON Traffic Controller is designed to be compatible with the latest SCATS ® generations.
• New releases can be upgraded on site.

Ramp Metering:

• Full application for Ramp Metering can be achieve with the HADRON Traffic Controller.
• Ramp Metering is based on the data collection using loop detectors.

Road Site Processor:

1. Traffic Data Collection

• Speed
• Volume

2. Incident Detection.

Lane Controller:

• All lane changes are protected by conflict matrix
• Lamp Monitoring for enhanced safety.

Safety and Dependability:

1. Monitored MTBF >80,000 hours
2. Conflict Monitoring

• Conflict checking BEFORE Lights displayed
• Lamp Drive vs Lamp Status verification
• Conflict checking of the Lights displayed
• Last RED detection
• Independent (secondary) Conflict Monitoring

3. Lamp Monitoring

• Will operate with most lantern types automatically
• Lamp failure monitoring (all lantern types)
• Reports REAL power

4. SCATS ® communications options

• Protocols supported (user field configurable)
  • Original
  • HDLC
• Leased Line
• Dialup line
• ADSL (IP based)
• TCP/IP (IP based communication options support all protocols)

Technical Specifications: Design and Manufactured under ISO 9001:2008.

Outputs (signals):

• Up to 8 Modules of 4 groups each (12 Aspects i.e. 3 Aspects per group)
• Aspect drive capability up to 5 Amps
• Fuse protection 8A HRC
• Aspect power measurement resolution 0.5W
• All aspects voltages and currents measured simultaneously
• Aspect voltages individually set as per Aspect (channel)
• Load Handling PF 0.95 leading (capacitive) to 0.6 lagging

Outputs (auxiliary):

• Output – Wait Indicators Drives
• Open Collector Outputs, Active Low with fly-back diode to +24V rail
• 300 Ohm minimum load resistance
• 24V DC Supply, 1 Amp current limited (total from module including Daily Event Output)

Output – Daily Event Drive:

• Open Collector Output, Active Low, with fly-back diode to +24V rail
• 75 Ohm minimum load Resistance
• 24V DC Supply, 1 Amp current limited (total per module including Wait Outputs)

Inputs:

• Up to 3 Modules (16 or 32 inputs with Wait indicator and Daily Event drives each)
• External contact Closure Nominal 32V AC 10mA
• Operational Voltage Range 24 to 40 V AC
• Operational Frequency Range 48 to 52 Hz
• Internal Input Loading 3,300 Ohms to 32 V AC Supply
• Internal Input Loading >100K Ohms (protection circuitry Triggered)
• Protection Circuit Trigger 50V AC.
